Organic membrane separation machine

Organic membrane separation experimental machine (equipment model: BONA-GM-18H)

Model: BONA-GM-18H
Technical Parameters:
1. Minimum circulation volume: 0.8L;
2. Material tank: 5L/10L jacketed with hot and cold water;
3. Working pressure: 0-4.0/6.5MPa;
4. Allowable working temperature: 5-55℃;
5. Pump power: 1500W;
6. The applicable range of pH: 2-12;
7. Filtration rate: 0.5-10L/H;
8. Cleaning temperature: 30~55℃
9. Power supply: AC/220V
10. Equipment size: 900 (length) × 490 (width) × 625 (height) mm
Product features and process introduction:
1. The equipment has an automatic overpressure protection function, and the overpressure automatically stops; to ensure the safety of the use process;
2. With temperature protection function, high temperature automatic shutdown, low temperature automatic start;
3. With temperature control module, over-temperature automatic shutdown to ensure the stability of materials during the experiment; high and low temperature alarms can be set to automatically start and stop;
4. It can be replaced with other types of microfiltration, ultrafiltration, nanofiltration membrane, and reverse osmosis membrane elements;
5. The equipment is equipped with pressure and temperature sensors, and the digital display screen displays pressure and temperature;
6. All stainless steel welding adopts automatic argon filling protection, single-sided welding, double-sided forming, and there is no welding point in contact with the material to ensure the pressure and corrosion resistance of the equipment;
7. The internal and external surfaces of the equipment pipes are of high quality, easy to operate, clean and hygienic, safe and reliable;
8. The equipment power supply adopts frequency conversion control, which can fully guarantee the safety of equipment and personnel;
9. Membrane element: Imported membrane element is used, and the type of membrane element is configured: the membrane element is configured according to the filtration requirements. The membrane element complies with the US FDA, USDA, 3-A sanitary standards;
10. According to the fluid dynamics, the membrane shell can ensure the flow rate of the membrane surface, ensure the safety of the experiment and the reliability and stability of the test data;
11. Configure the flow range of the pump completely according to the membrane surface flow rate of the sanitary membrane element, which can ensure that the experimental parameters selected by the equipment can be directly put into industrial production;
12. The thickened membrane shell design can be replaced with membrane cores such as microfiltration membranes, ultrafiltration membranes, and nanofiltration membranes, which are suitable for small-scale separation experiments;

Main equipment accessories:
One feed pump (imported), one SUS316L stainless steel membrane module, one pressure sensor, one temperature sensor, one material tank, one pressure regulating valve, equipment brackets, interlocking joints, pipes and several connecting parts, One set of over-pressure automatic protection system, one set of over-temperature automatic protection system, one set of frequency conversion control system, one membrane element.

Bona technical advantages:
1. Independently completed a number of domestic and foreign membrane equipment projects, with rich experience;
2. Have a group of senior engineers in membrane engineering application with many years of technology development and engineering practice;
3. Professional technical support can be provided on-site to guide installation and commissioning;
4. Complete customer service system, and equipment quality is guaranteed;
5. The company has a service center to provide you with fast, efficient and affordable instrument maintenance services.
